Camera
- Image Sensor: 2 MP CMOS
- Max. Resolution: 1920 (H) × 1080 (V)
- Min. Illumination: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Time: PAL: 1/12.5 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
- Day & Night: ICR
- Angle Adjustment: Pan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0° to 360°
- Signal System: PAL/NTSC
Lens
- Lens Type: 2.8 mm, 3.6 mm fixed lens
- Focal Length & FOV:
2.8 mm, horizontal FOV: 105°, vertical FOV: 59°, diagonal FOV: 127°;
3.6 mm, horizontal FOV: 87°, vertical FOV: 46°, diagonal FOV: 105°
- Lens Mount: M12
Microphone
- Pickup Distance: In a radius of up to 5 m
- Amount: 1
Speaker
- Rated Power: 2 W
- Speaker Range: In a radius of up to 5 m
Illuminator
- Supplement Light Type: Smart,IR,White Light
- Supplement Light Range: IR: Up to 30 m,White Light: Up to 20 m
- Image Settings:
Anti-banding, Brightness, Sharpness, Smart IR
- Frame Rate: TVI: 1080p @25 fps/30 fps
- Day/Night Mode: Auto/Color
- Wide Dynamic Range (WDR): Digital WDR
- Image Enhancement:
DWDR, BLC, HLC, Global, HLS
- Noise Reduction: 2D DNR
- White Balance:
Auto, Manual
Audio
- Audio Function: Echo Cancellation, AI Noise Reduction, Automatic Gain Control
Interface
- Video Output: 1 HD analog output
- Alarm: Flashing Light Alarm (Red & Blue)
General
- Power:
12 VDC ± 25%, max. 7.7 W, *You are recommended to use one power adapter to supply the power for one camera. If a high-impedance cable is used (such as the 18 m extension cable in the kit package), a 15 VDC adapter is required.
- Material: Metal
- Dimension: 179 mm × 66 mm × 69.1 mm (7.05″ × 2.6″ × 2.72″) Approx. 435 g (0.96 lb.)
- Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
- Communication: HIKVISION-C
- Language: English
Approval
- Protection: IP67
